3/8" Santoprene Food Grade Chilling and Heating Tubing -75F to 275F

Material: Santoprene Tubing Dimension: 3/8″ ID X 5/8″ OD X 1/8″Wall Uses: This tubing is for use with all Ai Heating units and for C30 Recirculating Units, Shore Hardness: Hardness Typical Value (English) Typical Value (SI) Test-Based On Shore A 15 sec 73℉ (23℃) 78 78 ISO 868 Physical Characteristics Physical Typical Value (English) Typical Value (SI) Test-Based On Density / Specific Gravity 0,960 0,960 ASTM D792 Desity 0,960 g/cm^3 0,960 g/cm^3 ISO 1183 Temperature and Pressure Extrusion Typical Value (English) Typical Value (SI) Drying Temperature 180 ℉ 82 ℃ Drying Time 3,0 hr 3,0 hr Melt Temperature 395 ℉ 202 ℃ Die Temperature 400 ℉ 204 ℃ Back Pressure 725 to 2900 psi 5,00 to 20,0 MPa Tubing Operating Pressure: Not to exceed 50 psi Operating Temperature: -75F to 275F Compliance FDA Food contact Unspecified rating NSF STD-51 UL QMFZ2 UL QMFZ8
